Uses and benefits
The Super Midi is designed for high-speed cleaning with a range of specialized Cleaning Chains. Excellent for unblocking and removing roots, as well as reinstating CIPP connections. Add the Maxi Coating Pump to offer the Picote Brush Coating™ System. Weighs 69kg /152 lbs, 500 to 1500 rpm, 1.5kW output. Lightweight aluminum frame.
Standard safety features include: protective outer shaft casing making the cable safe to hold, shielded operator presence foot control, safety clutch, emergency stop switch.
Technical spec
| Cleaning / Descaling |
DN70-150 (3-6") |
| Cutting / Reinstatement |
DN70-150 (3-6") |
| Picote Brush CoatingTM |
DN70-200 (3-8")
|
| Range |
20m / 65ft + 10m /32ft extension
|
| Additional Models |
Super Midi with 10mm / ⅜" shaft (Midi Cleaner), please see Midi Cleaner page for specs of this model
|
How to use
The Picote Super Midi is suitable for a wide range of work inside DN70-150 / 3-6" pipes:
Descaling | Root Cutting | Reinstatements | Unblocking | Brush Coating | Removing Failed Patches | Cutting Out Intruding Connections | Removing Metal Rebar | Removing Grout | Trimming Back Overshot CIPP Lining
Excellent 'First Fix' machine for removing baby wipes and other blockages.
Original Standard Chain
Original Standard Chains available for⅓", ⅜" & ½" Shaft
Cyclone Standard Chain
Cyclone Standard Chains available for⅓", ⅜" & ½" Shaft
Original Premium Chain
Original Premium Chains available for⅓", ½" & ¾" Shaft. For Midi Cleaner with ⅜" Shaft, use a Shaft Connector
Tiger Original Chain
Tiger Original Chains available for⅓", ⅜" & ½" Shaft
Tiger Drill Chain
Tiger Drill Chains available for ⅓", ⅜" & ½" Shaft
Original PVC Chain
Original PVC Chains available for⅓", ⅜" & ½" Shaft
3D Premium Chain
3D Premium Chains available for⅓" & ½" Shaft. For Midi Cleaner with ⅜" Shaft use a Shaft Connector
3D PVC Chain
3D PVC Chains available for⅓" & ½" Shaft. For Midi Cleaner with ⅜" Shaft use a Shaft Connector
Cyclone Premium Chain
Cyclone Premium Chains available for⅓" & ½" Shaft. For Midi Cleaner with ⅜" Shaft use a Shaft Connector.
Cyclone PVC Chain
Cyclone PVC Chains available for⅓", ⅜" & ½" Shaft
Tiger Cyclone Chain
Tiger Cyclone Chains available for⅓", ⅜" & ½" Shaft
Special Drill Head Cutter
Special Drill Heads for reinstatements and cleaning. Available for ⅓" & ½" (8 & 12mm) shafts.
Shaft Connector
Shaft Connectors available for ⅓", ⅜" & ½" shafts (8mm, 12mm & 18mm shafts). Not suitable for Mini Cleaner.
Sleeve
Sleeves for shafts. Available for ⅓", ⅜" & ½" shafts (8mm, 12mm & 18mm shafts). Not suitable for Mini Cleaners.
Tiger Bore
Tiger Bores for reinstatements and cleaning. Available for ⅓" & ½" (8 & 12mm) shafts.
Flexible Shaft Extension
Extension shafts available for all Miller models except the Mini Cleaner.
Replacement Flexible Shaft
Replacement Flexible Shafts available for all Miller models.
Leader
Leaders used to connect tools quickly. Available in ⅓", ⅜", ½" & ¾" (8, 10, 12 & 18mm) shaft sizes
Pipe Cutter
Pipe Cutter/Pipe Cutter Ultra Flex. Use to cut overshot liners in bent or straight sections of pipe.
Smart Spider
Smart Spider for removing fats, oil & grease, and descaling fragile pipe. Available for ½" (12mm) shafts only.
Twister Metal Grinder
Twister Metal Grinder grinds away most metal including rebar, steel rods, nails, screws and lead joints in DN100 pipes.
Twister Cleaner
Twister Cleaner for light cleaning and working in plastic and deformed & blistered pitch fibre pipes.
Maxi Pump Bracket
Maxi Pump Bracket attaches the Maxi Coating Pump to a Midi Cleaner or Super Midi
Wire Cleaning Brushes
Metal cleaning brush for removing fine dust or light mineral deposits in PVC & fragile pipes. Also used for Picote Brush Coating® preparation.
Shaft Lubricant
Shaft Lubricant Oil, for rotating Miller shafts
